PV Nh Fuse Base Compact Nh Sizes

Basic Info

Model NO.	CF0002
Form of Installation	Insurance Piece Holder
Environmental Protection	Environmental Protection Fuse Holder
Execution Standard	National Standard
Transport Package	Standard Export Carton
Specification	1000 Vdc
Origin	China
HS Code	8536100000
Production Capacity	100000 Piece/Pieces Per Month

Product Description

The construction of renewable energy infrastructure depends on economic drivers and is under increasing pressure to achieve parity with traditional sources of electricity. Reducing the cost of installing photovoltaic (PV) systems is a key focus of the solar industry. NH fuses bases can offered a compact, safe and economic circuit protect solution for solar system. As one of the solar broad portfolio of fuse products, the 1000Vdc CFPV NH fuses holders are specifically designed for the protection of photovoltaic system. The rated voltage of this series of fuse bases are up to 1000Vdc, the rated current are up to400A, and the rated breaking capacity is up to 30KA.

Features & Benefits
Compact NH sizes
Low watt loss
1000 V dc rating for high efficiency designs
Full range production

Application
Inverters
Re-combiner boxes
Array/re-combiner application
PV inverter dc input protection

Supply Ability100000 Piece/Pieces per Month

Packaging & DeliveryPackaging Detailspacking by standard export carton, or according to customer's requestLead Time:Quantity(Pieces) 1 - 5000 >5000Est. Time(days) 20 To be negotiated

Specification

Model Number	CFPV-H bases
Basic fuse size	NH00 NH1 NH2 NH3 size
Ratings
Voltage	1000 Vdc
Current	400A
Operating class	gPV and UL PV Fuse Links
Comply standards	UL® Listed to 248-19, Guide JFGA,
	IEC® 60269-6 (gPV)
Country of Origin	China
